Air cooling
You are here:
W3
CPU SUPPORT
Ampere® Altra® Family
CPU SOCKET
LGA4926
APPLICATION
Tower PC
MAXIMUM POWER
250 W
Additional Information
| CPU Support | Ampere® Altra® Family |
| CPU Socket | LGA 4926 |
| Solution | Tower PC |
| Dimension | 141.1 x 84.0 x 72.0 mm |
| Weight | 706 ± 10 g |
| Material | Aluminum + Direct Contact Heat Pipe Heatsink Base + Aluminum Fins |
| Fan Model | LE12250013 |
| Fan Dimension | 120 x 120 x 25 mm |
| Bearing | Double Ball |
| Rated Voltage | 12V |
| Rated Speed | At Duty Cycle 0~20%: 600 ± 200 RPM
At Duty Cycle 50%: 1500 ± 200 RPM At Duty Cycle 100%: 2200 ± 10% RPM |
| Input Power | At Duty Cycle 0~20%: 0.6 W
At Duty Cycle 50%: 1.2 W At Duty Cycle 100%: 2.4 W |
| Maximum Airflow | At Duty Cycle 0~20%: 21.2 CFM
At Duty Cycle 50%: 57.5 CFM At Duty Cycle 100%: 84.3 CFM |
| Rated Static Pressure | At Duty Cycle 0~20%: 0.24 mm-H2O
At Duty Cycle 50%: 1.76 mm-H2O At Duty Cycle 100%: 3.78 mm-H2O |
| Acoustical Noise | At Duty Cycle 0~20%: 14.26 dBA
At Duty Cycle 50%: 27.7 dBA At Duty Cycle 100%: 36.1 dBA |
| Lead Wire Pin Out | Pin#1- Black(-)
Pin#2- Black(+) Pin#3- Black(Tachometer/ Signal Output) Pin#4- Black(PWM) |
| Thermal Grease | Shin-Etsu X23-8079-2 provided by the syringe |
