Air cooling
You are here:
T450
CPU SUPPORT
Intel
CPU SOCKET
LGA1200/115X
APPLICATION
1.5U
MAXIMUM POWER
65W
Additional Information
| CPU Support | Intel |
| CPU Socket | LGA 115X/1200 |
| Screw Type | M3 |
| Installation Torque | 5-7 in-lb |
| Dimensions | 93.0 x 31.0mm |
| Solution | 1.5 U, Mini-ITX (with chassis height 2 inch & up) |
| Weight | 185 g |
| Fan Dimension | 80 x 80 x 15 mm |
| Material | Aluminum 6063-T5 Extruded Radial Fin |
| Rated Voltage | 12V |
| Speed | At Duty Cycle 20%: 800 RPM At Duty Cycle 50%: 1500 RPM At Duty Cycle 100%: 2500 RPM |
| Bearing | 2 Ball Bearing |
| Power | At Duty Cycle 20%: 0.36 W At Duty Cycle 50%: 0.6 W At Duty Cycle 100%: 2.4 W |
| Air Flow | At Duty Cycle 20%: 9.24 CFM At Duty Cycle 50%: 18.48 CFM At Duty Cycle 100%: 30.80 CFM |
| Noise Level | At Duty Cycle 20%: 16.0 dBA At Duty Cycle 50%: 22.0 dBA At Duty Cycle 100%: 27.3 dBA |
| Air Pressure | At Duty Cycle 20%: 0.42 mm-H2O At Duty Cycle 50%: 1.93 mm-H2O At Duty Cycle 100%: 2.6 mm-H2O |
| Lead Wire Pin Out | Pin1- (-) Pin2- (+) Pin3- (Techometer/Signal output) Pin4- (PWM) |
| Life – Continuous operating
under normal temperature (40 °C or 104 °F) |
70,000 Hours |
