S4

CPU SUPPORT
Intel

CPU SOCKET

LGA4677

APPLICATION
1U

MAXIMUM POWER

205 W

Note:

Dynatron S2, S3, S4, S5, S5R1, S6, and S7 each come with the E1A and E1B Package Carrier. The E1C Package Carrier is not included but is available upon request.

To find out which Package Carrier corresponds to your processor, please visit the official Intel link for more information. Click here to see the guideline example.

Additional Information

CPU Support Intel® Sapphire Rapids Processor
CPU Socket Socket FCLGA 4677
Screw Type #8-32
Installation Torque 8 in-lb
Solution 1U Server
Dimensions 118 x 78 x 27 mm
Weight 437.60 g
Material Copper Vapor Chamber and Fin Stack
Thermal Grease Pre-Printed with SHIN-ETSU 7762 or Equivalent
Life – Continuous operating

under normal temperature

(40 °C or 104 °F)

70,000 Hours
