Air cooling

You are here:

I31G

CPU SUPPORT
Intel

CPU SOCKET

PGA479

APPLICATION
1U

Additional Information

CPU Support Intel
CPU Socket PGA479
Solution 1U Server
Dimensions 50.0 x 50.0 x 25.0 mm
Weight 110g ± 5g
Material Copper
Fan Dimension 40 x 40 x 10 mm
Speed 5500 RPM
Bearing 2 Ball Bearing
Rated Voltage 12V
Power 1,44 Watts
Air Flow 4.57 CFM
Noise Level 25.068 dBA
Static Pressure 0.077inch-H2O
Lead Wire Pin Out Pin1-Black (GND)

Pin2-Red (PWR)

Pin3-Techometer/Signal output
