Air cooling
You are here:
T768
CPU SUPPORT
Intel
CPU SOCKET
LGA1200/115X
APPLICATION
3U & UP
MAXIMUM POWER
125 W
Additional Information
| CPU Support | Intel |
| CPU Socket | LGA 115X/1200 |
| Screw Type | M3 |
| Installation Torque | 5-7 in-lb |
| Solution | 3U and Up, Workstation |
| Dimensions | 98.0 x 98.0 x 110.0 mm |
| Weight | 538 g |
| Material | Aluminum Fins, 4x Heat Pipes with H.C.C. Technology |
| Fan Dimension | 92 x 92 x 25 mm |
| Speed | At Duty Cycle 20%: 1000 RPM At Duty Cycle 50%: 1800 RPM At Duty Cycle 100%: 2500 RPM |
| Rated Voltage | 12V |
| Bearing | 2 Ball Bearing |
| Power | At Duty Cycle 20%: 0.96 W At Duty Cycle 50%: 1.44 W At Duty Cycle 100%: 3.0 W |
| Air Flow | At Duty Cycle 20%: 17.34 CFM At Duty Cycle 50%: 31.21 CFM At Duty Cycle 100%: 43.36 CFM |
| Noise Level | At Duty Cycle 20%: 17.0 dBA At Duty Cycle 50%: 24.78 dBA At Duty Cycle 100%: 31.92 dBA |
| Air Pressure | At Duty Cycle 20%: 0.48 mm-H2O At Duty Cycle 50%: 1.55 mm-H2O At Duty Cycle 100%: 3.0 mm-H2O |
| Lead Wire Pin Out | Lead Wire Pin Out Pin1- (-) Pin2- (+) Pin3- (Techometer/Signal output) Pin4- (PWM) |
| Life – Continuous operating
under normal temperature (40 °C or 104 °F) |
70,000 Hours |
