Air cooling
You are here:
R9
CPU SUPPORT
Intel
CPU SOCKET
LGA2011/2066/SQUARE
APPLICATION
2U
MAXIMUM POWER
165W
Additional Information
CPU Support | Intel |
CPU Socket | LGA 2011 (Square Type, 80mm x 80mm Mounting Pitch) |
Screw Type | M4 |
Installation Torque | 10-16 in-lb |
Solution | 2U Server and Up |
Dimensions | 90.0 x 90.0 x 62.0 mm |
Weight | 490 g |
Material | Aluminum Extruded Radial Fin Heatsink with Copper Inserted |
Fan Dimension | 77 x 77 x 20 mm |
Bearing | 2 Ball Bearing |
Fan Speed | At Duty Cycle 20%: 1000 RPM At Duty Cycle 50%: 2500 RPM At Duty Cycle 100%: 4500 RPM |
Rated Voltage | 12V |
Power | At Duty Cycle 20%: 0.84 W At Duty Cycle 50%: 1.44 W At Duty Cycle 100%: 6.0 W |
Air Flow | At Duty Cycle 20%: 10.12 CFM At Duty Cycle 50%: 25.30 CFM At Duty Cycle 100%: 45.56 CFM |
Noise Level | At Duty Cycle 20%: 13.14 dBA At Duty Cycle 50%: 33.04 dBA At Duty Cycle 100%: 45.9 dBA |
Air Pressure | At Duty Cycle 20%: 0.185 mm-H2O At Duty Cycle 50%: 1.156 mm-H2O At Duty Cycle 100%: 3.746 mm-H2O |
Lead Wire Pin Out | Pin1- (-) Pin2- (+) Pin3- (Techometer/Signal output) Pin4- (PWM) |
Life- Continuous operating
under normal temperature (40°C/104 °F) |
70,000 Hours |
