Air cooling
You are here:
R8
CPU SUPPORT
Intel
CPU SOCKET
LGA2011/2066/SQUARE
APPLICATION
2U
MAXIMUM POWER
165W
Additional Information
| CPU Support | Intel |
| CPU Socket | LGA 2011 (Square Type, 80mm x 80mm Mounting Pitch) |
| Screw Type | M4 |
| Installation Torque | 10-16 in-lb |
| Solution | 2U Server and Up |
| Dimensions | 90.0 x 90.0 x 64.0 mm |
| Weight | 490 g |
| Material | Copper Base with Aluminum Stacked Fin with 3 Heatpipes |
| Life- Continuous operating
under normal temperature (40°C/104 °F) |
70,000 Hours |
