Air cooling
You are here:
R18
CPU SUPPORT
Intel
CPU SOCKET
LGA2011/2066/SQUARE
APPLICATION
1U
MAXIMUM POWER
165W
Additional Information
| CPU Support | Intel |
| CPU Socket | LGA 2011 (Square Type, 80mm x 80mm Mounting Pitch) / LGA 2066 |
| Screw Type | M4 |
| Installation Torque | 10-16 in-lb |
| Solution | 1U Server |
| Dimensions | 90.0 x 90.0 x 27.7mm |
| Weight | 480 g |
| Material | Copper Heatsink with Skiving Fins |
| Fan Dimension | 80 x 80 x 15 mm |
| Speed | At Duty Cycle 20%: 1000 RPM At Duty Cycle 50%: 3500 RPM At Duty Cycle 100%: 6000 RPM |
| Bearing | 2 Ball Bearing |
| Rated Voltage | 12V |
| Power | At Duty Cycle 20%: 0.6 W At Duty Cycle 50%: 3.84 W At Duty Cycle 100%: 14.4 W |
| Air Flow | At Duty Cycle 20%: 6.5 CFM At Duty Cycle 50%: 11.2 CFM At Duty Cycle 100%: 19.1 CFM |
| Noise Level | At Duty Cycle 20%: 21.5 dBA At Duty Cycle 50%: 43.0 dBA At Duty Cycle 100%: 55.8 dBA |
| Air Pressure | At Duty Cycle 20%: 2.27 mm-H2O At Duty Cycle 50%: 18.56 mm-H2O At Duty Cycle 100%: 54.5 mm-H2O |
| Lead Wire Pin Out | Pin1- (-) Pin2- (+) Pin3- (Techometer/Signal output) Pin4- (PWM) |
| Life- Continuous operating
under normal temperature (40°C/104 °F) |
70,000 Hours |
