L34
CPU SUPPORT
Intel | AMD
CPU SOCKET
Intel Socket |
LGA1851/1700, LGA1200/115X
LGA2011/2066/SQUARE
LGA1356/1366
AMD Socket |
AM4/AM5
FM2+/FM2/AM2/AM2+/AM3/AM3+/FM1
APPLICATION
2U
MAXIMUM POWER
Intel – 300 W
AMD – 205 W
Additional Information
| CPU Support | Intel & AMD |
| CPU Socket | LGA115x, LGA1366, LGA1700, LGA2011/2066 Square ILM
AM2/AM3/AM4/AM5/FM1/FM2 |
| Screw Type | #6-32/M3/M4 |
| Installation Torque | 6-10 in-lb/5-7 in-lb/10-16 in-lb |
| Solution | 2U Server and Up |
| Fan Dimension | 80 x 80 x 38 mm |
| Cold Plate Dimension | 64.5 x 64.5 x 23 mm |
| Radiator Dimension | 383.5 x 86.5 x 85.4 mm |
| Speed | At Duty Cycle 0~20%: 1350 ± 200 RPM At Duty Cycle 50%: 3100 ± 10% RPM At Duty Cycle 100%: 6000 ± 5% RPM |
| Bearing | 2 Ball Bearing |
| Rated Voltage | 12V |
| Power | At Duty Cycle 0~ 20%: 1.20 W At Duty Cycle 50%: 3.84 W At Duty Cycle 100%: 22.8 W |
| Noise Level | At Duty Cycle 0~ 20%: 24.77 dBA At Duty Cycle 50%: 42.82 dBA At Duty Cycle 100%: 57.16 dBA |
| Air Flow | At Duty Cycle 0~ 20%: 23.085 CFM At Duty Cycle 50%: 53.01 CFM At Duty Cycle 100%: 102.60 CFM |
| Air Pressure | At Duty Cycle 0~ 20%: 1.152 mm-H2O At Duty Cycle 50%: 6.074 mm-H2O At Duty Cycle 100%: 22.752 mm-H2O |
| Lead Wire Pin Out | Pin1- (-) Pin2- (+) Pin3- (Tachometer/Signal output) Pin4- (PWM) |
| Life – Continuous operating
under normal temperature (40 °C or 104 °F) |
70,000 Hours |
