Air cooling
You are here:
G199
CPU SUPPORT
Intel
CPU SOCKET
LGA1356/1366
APPLICATION
1U
MAXIMUM POWER
140 W
Additional Information
CPU Support | Intel |
---|---|
CPU Socket | LGA 1356/1366 |
Solution | 1U Server |
Dimensions | 90.0mm x 90.0mm x 27.8mm |
Weight | 475g ±5g |
Material | Copper Heatsink with Skiving Fins |
Fan Dimension | 70mm x 70mm x 16mm |
Speed | At Duty Cycle 20%: 1100+ 10%RPM At Duty Cycle 50%: 2600+ 10%RPM At Duty Cycle 100%: 6000+ 10%RPM |
Bearing | 2 Ball Bearing |
Rated Voltage | 12V |
Power | At Duty Cycle 20%: 0.60 W At Duty Cycle 50%: 1.20 W At Duty Cycle 100%: 8.76 W |
Air Flow | At Duty Cycle 20%: 2.45 CFM At Duty Cycle 50%: 5.80 CFM At Duty Cycle 100%: 14.32 CFM |
Noise Level | At Duty Cycle 20%: 19.1 dBA At Duty Cycle 50%: 34.2 dBA At Duty Cycle 100%: 53.8 dBA |
Static Pressure | At Duty Cycle 20%: 1.252mm-H2O At Duty Cycle 50%: 6.997mm-H2O At Duty Cycle 100%: 50.458mm-H2O |
Lead Wire Pin Out | Pin1-Black (-) Pin2-Yellow (+) Pin3-Green (Techometer/Signal output) Pin4-Blue (PWM) |
