Air cooling
You are here:
B3
CPU SUPPORT
Intel
CPU SOCKET
LGA3647/NARROW
APPLICATION
1U
MAXIMUM POWER
165W
Additional Information
| CPU Support | Intel |
| CPU Socket | FCLGA 3647 |
| Screw Type | M4 |
| Installation Torque | 12 in-lb |
| Solution | 1U Server and Up |
| Dimensions | 107.0 x 80.5 x 28.0 mm |
| Weight | 460 g |
| Material | Copper 1100 with Skived Fins |
| Fan Dimension | 80 x 15 mm |
| Speed | At Duty Cycle 20%: 1000 ± 200 RPM At Duty Cycle 50%: 4000 ± 10% RPM At Duty Cycle 100%: 7000 ± 10% RPM |
| Rated Voltage | 12V |
| Bearing | 2 Ball Bearing |
| Power | At Duty Cycle 20%: 0.60 W At Duty Cycle 50%: 3.84 W At Duty Cycle 100%: 19.2 W |
| Air Flow | At Duty Cycle 20%: 3.0 CFM At Duty Cycle 50%: 12.0 CFM At Duty Cycle 100%: 21.0 CFM |
| Noise Level | At Duty Cycle 20%: 16 dBA At Duty Cycle 50%: 44.9 dBA At Duty Cycle 100%: 57.1 dBA |
| Air Pressure | At Duty Cycle 20%: 1.5 mm-H2O At Duty Cycle 50%: 23.2 mm-H2O At Duty Cycle 100%: 70.9 mm-H2O |
| Lead Wire Pin Out | Lead Wire Pin Out Pin1- (-) Pin2- (+) Pin3- (Techometer/Signal output) Pin4- (PWM) |
| Thermal Grease | Shin-Etsu 7762 or Equivalent |
| Life – Continuous operating
under normal temperature (40 °C or 104 °F) |
70,000 Hours |
*Please refer to this installation method, if there any discrepancies or questions, please contact us!
