Air cooling
You are here:
A35
CPU SUPPORT
AMD
CPU SOCKET
sWRX8/sTRX4/TR4/SP3
APPLICATION
3U & UP, Workstations
MAXIMUM POWER
280 W
Additional Information
| CPU Support | AMD |
| CPU Socket | AMD® Socket sWRX8/sTRX4/TR4/SP3 |
| Screw Type | M3.5 |
| Installation Torque | 12.5-15.1 in-lb |
| Solution | 3U Server and up, Workstations |
| Dimensions | 120 x 82 x 110 mm (L×W×H) |
| Weight | 600g |
| Material | Aluminum Heatsink with Heatpipe Embedded |
| Fan Dimension | 80 x 80 x 38 mm |
| Speed | 3800 RPM |
| Bearing | 2 Ball Bearing |
| Rated Voltage | 12V |
| Power | 8.2 Watts |
| Air Flow | 68.4 CFM |
| Noise Level | 16.0~48.4 dBA |
| Life – Continuous operating
under normal temperature (40 °C or 104 °F) |
70,000 Hours |
