Air cooling
You are here:
Z60
CPU SUPPORT
Intel
CPU SOCKET
Intel Socket |
LGA1851/1700
APPLICATION
1.5U
MAXIMUM POWER
65 W
Additional Information
| CPU Support | Intel |
| CPU Socket | LGA 1700 |
| Screw Type | M3 |
| Installation Torque | 5-7 in-lb |
| Solution | 2U Server & Up |
| Dimensions | 93.0 x 93.0 x 31.3 mm |
| Weight | 185±5 g |
| Material | Aluminum 6063-T5 Extuded Raidal Fin Heat Sink |
| Fan Dimension | 80 X 80 X 15 mm |
| Speed | At Duty Cycle 0~20%: 800 RPM
At Duty Cycle 50%: 1500 RPM At Duty Cycle 100%: 2500 RPM |
| Bearing | Double Ball |
| Rated Voltage | 12V |
| Power | At Duty Cycle 0~20%: 0.36 W
At Duty Cycle 50%: 0.6 W At Duty Cycle 100%: 2.4 W |
| Air Flow | At Duty Cycle 0~20%: 9.24 CFM
At Duty Cycle 50%: 18.48 CFM At Duty Cycle 100%: 30.80 CFM |
| Noise Level | At Duty Cycle 0~20%: 16.00 dBA
At Duty Cycle 50%: 22.0 dBA At Duty Cycle 100%: 27.3 dBA |
| Static Pressure | At Duty Cycle 0~20%: 0.23 mm-H2O
At Duty Cycle 50%: 0.93 mm-H2O At Duty Cycle 100%: 2.60 mm-H2O |
| Lead Wire Pin Out | Pin1-Black (-) Pin2-Yellow (+) Pin3-Green (Techometer/Signal output) Pin4-Blue (PWM) |
| Life – Continuous operating
under normal temperature (40 °C or 104 °F) |
70,000 Hours |
*Please refer to this installation method,
if there any discrepancies or questions, please contact us!
