Air cooling
You are here:
!!!參考商品!!!
CPU SUPPORT
AmpereOne
CPU SOCKET
LGA5964
APPLICATION
2U
MAXIMUM POWER
TBD
| CPU Support | |
|---|---|
| Intel CPU Socket | LGA1851 / 1700, LGA1200 / 115X, LGA2011 / 2066 / NARROW, LGA2011 / 2066 / SQUARE, LGA1356 / 1366 |
| AMD CPU Socket | |
| APPLICATION | |
| 顏色 | 紅, 黑, 白 |
Additional Information
Variations
| CPU Support | Intel/AMD |
| CPU Socket | Intel Socket LGA 2011/2066 Square/LGA 115X/1200/1356/1366/1700
AMD AM4/AM5/FM2 + /FM2/AM2/AM2 + /AM3/AM3 + /FM1 |
| Screw Type | #6-32/M3/M4 |
| Installation Torque | 6-10 in-lb/5-7 in-lb/10-16 in-lb |
| Solution | 1U Server |
| Fan Dimension | 40 x 40 x 28 mm |
| Cold Plate Dimension | 64.5 x 64.5 x 23.5 mm |
| Radiator Dimension | 188 x 74 x 40 mm |
| Speed | At Duty Cycle 0~20%: 3300±10% RPM
At Duty Cycle 50%: 5700±10% RPM At Duty Cycle 100%: 12000±10% RPM |
| Bearing | 2 Ball Bearing |
| Rated Voltage | 12V |
| Power | At Duty Cycle 0~20%: 0.72 W
At Duty Cycle 50%: 1.56 W At Duty Cycle 100%: 8.40 W |
| Noise Level | At Duty Cycle 20%: 25.9 dBA
At Duty Cycle 50%: 37.8 dBA At Duty Cycle 100%: 54.0 dBA |
| Air Flow | At Duty Cycle 0~20%: 5.92 CFM
At Duty Cycle 50%: 10.23 CFM At Duty Cycle 100%: 21.53 CFM |
| Air Pressure | At Duty Cycle 0~20%: 1.73 mm-H2O
At Duty Cycle 50%: 5.17 mm-H2O At Duty Cycle 100%: 22.91 mm-H2O |
| Lead Wire Pin Out | Pin1- (-)
Pin2- (+) Pin3- (Techometer/Signal output) Pin4- (PWM) |
| Water Pump | Stand-alone Water Pump with Powerful Flow Rate 1.7 Liter Per Minute |
| Radiator | Space Saver Light Weight Radiator |
| Cold Plate | Cold Plate Module with Copper Base |
| Life – Continuous operating
under normal temperature (40 °C or 104 °F) |
70,000 Hours |
Cold Plate Module with Copper BaseStand-alone Water Pump with Powerful Flow Rate 1.7 Liter Per Minute
| Model No. | DF125020BH | DF125020BM | DF125020BL | DF125020BE |
| Voltage | DC | DC | DC | DC |
| Voltage Range | 12 | 12 | 12 | 12 |
| Speed (RPM) | 5800 | 5300 | 4500 | 3700 |
| Bearing | Dual Ball | Dual Ball | Dual Ball | Dual Ball |
| Current (Amp) | 0.24 | 0.21 | 0.14 | 0.10 |
| Watts (W) | 2.88 | 2.52 | 1.68 | 1.20 |
| Air Flow (CFM) | 17.6 | 16.1 | 13.6 | 10.9 |
| Static Pressure (mm/H2O) | 6.6 | 5.5 | 4.0 | 2.9 |
| Noise (dBA) | 32 | 30.06 | 26.7 | 24.3 |
| RoHS | Compliance | Compliance | Compliance | Compliance |
Cold Plate Module with Copper Base
