Additional Information
| Dimensions | 70mm x 70mm x 15mm |
| Frame | Aluminum (GP) |
| Impeller | PBT UL94V-0 (Black GP) |
| Weight | 77±5grams |
| Operating Temperature | – 10 °C ~ + 65 °C (65 %RH) |
| Storage Temperature | – 30 °C ~ + 70 °C (65 %RH) |
| MTBF (Operating temp. 40°C) | Dual Ball Bearing: 70,000 hours |
| Connector Types | 4 Pin PWM |
| Model No. | DB127015BU -PWM | DB127015BH -PWM | ||
| Voltage | DC | DC | ||
| Voltage (V) | 12 | 12 | ||
| Speed (RPM) | 6000±10% | 5000±10% | ||
| Bearing | 2-Balls | 2-Balls | ||
| Current (Amp) | 0.73 | 0.46 | ||
| Watts (W) | 8.76 | 5.52 | ||
| Air flow (CFM) | 14.321 | 9.40 | ||
| Static Pressure (mm/H2O) | 50.458 | 26.40 | ||
| Noise (dBA) | 53.8 | 48.00 | ||
| RoHS | Compliance | Compliance |
