Air cooling
You are here:
B9
CPU SUPPORT
Intel
CPU SOCKET
LGA3647/SQUARE
APPLICATION
1U
MAXIMUM POWER
205W
Additional Information
| CPU Support | Intel® Xeon ® Platinum / Gold / Silver/ Bronze Family Processor (formerly Cascade Lake, Skylake) |
| CPU Socket | FCLGA 3647 Square ILM |
| Screw Type | M4 |
| Installation Torque | 12 in-lb |
| Solution | 1U Server and Up |
| Dimensions | 93 x 90.5 x 28 mm |
| Weight | 470 g |
| Material | Copper1100 Heatsink with Vapor Chamber Base |
| Fan Dimension | Ø90 x 15 mm |
| Speed | At Duty Cycle 20%: 1000 ± 200 RPM At Duty Cycle 50%: 2500 ± 10% RPM At Duty Cycle 100%: 5000 ± 10% RPM |
| Rated Voltage | 12V |
| Bearing | Ball Type, Double |
| Power | At Duty Cycle 20%: 1.2 W At Duty Cycle 50%: 2.6 W At Duty Cycle 100%: 12 W |
| Air Flow | At Duty Cycle 20%: 6.8 CFM At Duty Cycle 50%: 11.0 CFM At Duty Cycle 100%: 19.0 CFM |
| Noise Level | At Duty Cycle 20%: 16 dBA At Duty Cycle 50%: 31.5 dBA At Duty Cycle 100%: 46.4 dBA |
| Air Pressure | At Duty Cycle 20%: 2.8 mm-H2O At Duty Cycle 50%: 18 mm-H2O At Duty Cycle 100%: 46 mm-H2O |
| Lead Wire Pin Out | Lead Wire Pin Out Pin1- (-) Pin2- (+) Pin3- (Techometer/Signal output) Pin4- (PWM) |
| Thermal Grease | Shin-Etsu 7762 or Equivalent |
| Life – Continuous operating
under normal temperature (40 °C or 104 °F) |
70,000 Hours |
*Please refer to this installation method, if there any discrepancies or questions, please contact us!
