Air cooling
You are here:
A55
CPU SUPPORT
AMD
CPU SOCKET
AMD Socket |
SP6/TR5
APPLICATION
3U & UP, Workstations
MAXIMUM POWER
SP6: 225W
sTR5: 350W
Additional Information
| CPU Support | AMD® THREADRIPPER / AMD® THREADRIPPER PRO 7000 / AMD® EPYC™ Processor |
| CPU Socket | SP6/TR5 |
| Screw Type | M3.5 |
| Installation Torque | 12.5-15.1 in-lb |
| Solution | 3U Server and up, Workstations |
| Dimensions | 120 x 82 x 110 mm (L×W×H) |
| Weight | 656g |
| Material | Aluminum Heatsink with Heatpipe Embedded |
| Fan Dimension | 80 x 80 x 38 mm |
| Speed | At Duty Cycle 0~20%: 2400± 200 RPM
At Duty Cycle 50%: 4800± 10% RPM At Duty Cycle 100%: 8000±10% RPM |
| Bearing | 2 Ball Bearing |
| Rated Voltage | 12V |
| Power | At Duty Cycle 0~20%: 1.2 W At Duty Cycle 50%: 5.52 W At Duty Cycle 100%: 24.72 W |
| Air Flow | At Duty Cycle 0~20%: 35.52 CFM At Duty Cycle 50%: 67.24 CFM At Duty Cycle 100%: 115.61 CFM |
| Noise Level | At Duty Cycle 0~20%: 25.63 dBA At Duty Cycle 50%: 47.85 dBA At Duty Cycle 100%: 64.40 dBA |
| Life – Continuous operating
under normal temperature (40 °C or 104 °F) |
70,000 Hours |
