A48G
CPU SUPPORT
AMD
CPU SOCKET
FM2+/FM2/AM2/AM2+/AM3/AM3+/FM1
APPLICATION
1U
MAXIMUM POWER
115W
Additional Information
| CPU Support | AMD® |
|---|---|
| CPU Socket | FM2+/FM2/AM2/AM2+/AM3/AM3+/FM1 |
| Solution | 1U Server |
| Dimensions | 106 x 79 x 27.5 mm |
| Weight | 500g ± 5g |
| Material | Skived Copper Heatsink |
| Fan Dimension | 70 x 70 x 15 mm |
| Speed | At Duty Cycle 100%: 7000 ± 10% RPM |
| Power | At Duty Cycle 100%: 8.76 W |
| Bearing | 2 Ball Bearing |
| Rated Voltage | 12V |
| Air Flow | At Duty Cycle 100%: 12.83 CFM |
| Noise Level | At Duty Cycle 100%: 54.4 dBA |
| Air Pressure | At Duty Cycle 100%: 1.70 inch-H2O |
| Lead Wire Pin Out | Pin#1 – Black (-)
Pin#2 – Red (+) Pin#3 – White (Tachometer / Signal Output ) |
